BG-500x2 Automatic double-line continuous rolling flat folding garbage bag making machine
BG-500x2 Automatic double-line continuous rolling flat folding garbage bag making machine

BG-500x2 Automatic double-line continuous rolling flat folding garbage bag making machine

High-speed dual-channel roll-to-roll flat garbage bag making machine is an efficient and automated production equipment specially used for producing rolling flat garbage bags. It is suitable for producing garbage bags of various materials, such as HDPE, LDPE, biodegradable materials, etc. It adopts advanced production processes and technologies, and can efficiently and stably produce roll-to-roll flat-end garbage bags of various specifications. The equipment has the advantages of high degree of automation, high production efficiency, good sealing quality, small footprint, simple and convenient operation, etc., and is widely used in the field of garbage bag production.


Share:

Machine Specification :

1.Computer automatic control, automatic counting and setting alarm, high efficiency, saving manpower and time;

2.From film rolling to finished bags, it is fully automatic and one-time completion.

3.The length of domestic servo motor is fixed, photoelectric tracking is accurate and stable, and the  feeding is controlled by photoelectric.

4.Using hot-cutting device and intelligent temperature control system, the bag mouth is sealed firmly  and smoothly.

5.The main engine adopts frequency converter to control speed regulation.

6.Inverter control for feeding;

Technical Parameter:

Model

BG-500×2

Bag making width

200-400mm

Bag making length

400-1000mm

Bag making speed

50-280pcs/min

Bag makingthickness

0.006-0.025mm

Bag type

Coreless rolling supermarket bag

Heating power

8kw

Temperature control zone

4(4 Zones)

Total power

20kw

Total weight

2300kg

Overall dimension(L*W*H)

6500×2250×2000mm
