Main Technical Parameters
| Machine frame | 12mm thickness steel Plate |
| Main motor | 1.5KW motor, EURA inverter speed control |
| Front material feeding part | 2.3KW Servo motor feeding (WUXI ZEFU TECH) |
| Rear material feeding part | 0.4KW EURA Brand simulation automatic synchronous feeding. |
| Cutting knife | with transformer heating |
| Copper knife | middle heating tube and both sides of the heating plate double heating |
| The devices in the rear feeding part | with storage rack and loading by pneumatic |
| Width of bag making | 100-430mm |
| Length of bag making | 320-650mm |
| Bag making speed | 80-230pcs/channel/min, 160-460pcs/min/2channels |
| Switch, buttons | DELIXI or CHINT brand |
| Total Weight | 1400KGS |
| Overall dimension(L*W*H) | 4500*1750*1400mm |
| Voltage | 220V |
